PD5060-AC Series

5-Axis CO2 Laser Cutting Machine

PD5060-AC Series

Machine Features

1. Integrated natural marble base with fully enclosed structure, balanced force distribution, minimal vibration and superior machine stability

2. Modular design architecture, excellent component interchangeability

3. Metal RF laser source, long service life, reduced maintenance frequency and costs

4. High-precision DD motors and grating rulers, delivering exceptional consistency and accuracy.

5. Multi-axis CNC technology supporting cutting of various materials


Applications

Mainly designed for the laser cutting of 3D non-metallic materials, such as plastics, silicone, acrylic, wood, leather, PVC, KT board, fabric, paper, rubber, and other non-metallic materials.

Technical Data Sheet

Machine Model

PD5060-AC 5-Axis Series

Travel range

X-axis(mm)

600/240 (Planar /Curved surface machining)

Y-axis(mm)

500/240 (Planar/Curved surface machining)

Speed

Maximum rapid traverse speed (mm/s)

500

Maximum rapid traverse speed of Z axis (mm/s)

200

Accuracy

Positioning accuracy (mm)

±0.02

Repeatability accuracy (mm)

±0.01

Dimentional accuracy (mm)

±0.05

Laser Type

CO2

Optional laser power(W)

30,60,100,150

Mixmum seam width(mm)

0.07 (According to the material thickness)

 Weight(kg)

1500

Dimensions (L*W*H) (mm)

1600*1300*1800


Laser Cutting Effects
