Oscillating Laser Welding Head

FW202

Machine Features

1. Excellent performance on non-ferrous metals; greatly improves welding quality of aluminum alloy, copper and other materials

2. Reliable sealing, fully enclosed structure plus double lower protective lenses for longer service life

3. Optional accessories: Red light positioning, external blue light, coaxial gas blowing, side gas blowing, air curtain, display screen

4. Oscillating welding: Supports beam scanning paths including “O”,“8”,“∞”,“__”

5. Adjustable weld width ranging from 0 to 5 mm;

6. Compact structure, cost-effective and easy operation

Applications

Laser welding in industries including: automobile manufacturing, shipbuilding and construction engineering industries.

Technical Data Sheet

Machine Model	Oscillating Laser Welding Head FW202
Maximum Power	≤2kW
Collimation Focal Length	100mm
Focus Focal Length	200/250/300mm
Effective Clear Aperture	φ20mm
Cooling Water	0.5MPa、2L/min
Fiber Connector	QBH
Weight	≤2.5kg
Scanning Range	≤5mm
