LSMF6 series

Motor

LSMF6 series

Machine Features

1.Iron core technology with low cogging
2. Water or natural cooling; multi-series peak force up to 20000N
3. Optional hall sensor


Applications

Suitable for semiconductors, precision machine tools, medical equipment, 3C devices, display panels, PCB equipment, industrial automation and other applications.


Technical Data Sheet

Mover Spec.：LSMF610xxxx-x-H-NC-N-C00.5

701A-S

701B-S

702A-S

702B-S

703A-S

703A-P

704-S

704A-P

PERFORMANCE

PARAMETERS

Symbol

Unit

Series

Series

Series

Series

Series

Parallel

Series

Parallel

Continuous Force (Tmax）

Fc

N

109

109

226

212

468

468

361

362

Peak Force

Fp

N

259

259

532

500

1090

1090

830

834

Motor Constant (25℃)

Km25

N/Sqrt(W)

15.6

16.1

23.6

23.4

34.5

35.6

25.4

30.2

Max. Continuous

Power Dissipation

Pc

W

67

63

126

113

252

237

276

198

Continuous Current

 (Tmax）

Ic

Arms

6.0

2.8

6.0

4.5

6.0

12.0

3.7

8.0

Peak Current (1S)

Ip

Arms

18.0

8.4

18.0

13.5

18.0

36.0

11.1

24.0

Force Constant

(25℃，±5%）

Kf

N/Arms

18.3

38.7

37.5

47.1

78.0

39.0

97.5

45.3

Back EMF Constant

 (25℃，±5%）

Ke

Vrms/m/s

6.1

12.9

12.5

15.7

26.0

13.0

32.5

15.1

Electrical Resistance

(25℃，±5%）P-P

R

Ω

0.9

3.9

1.7

2.7

3.4

0.8

9.8

1.5

Inductance(25℃，±20%）

P-P

L

mH

11.8

53

23.6

37.4

47.2

11.8

85.0

18.2

Max Coil Temperature

Tmax

℃

120

120

120

120

120

120

120

120

Polar Distance (N-N)

(360℃ Electrical cycle)

2τ

mm

42

42

42

42

42

42

42

42

Magnetic Attraction

Fa

kN

0.5

0.5

1.0

1.0

2.0

2.0

1.5

1.5

Max.DC Bus Voltage

Ubus

V

600

600

600

600

600

600

600

600

Vmax,Fc@Vbus

=310Vdc


m/s

15.1

7.0

7.3

5.9

3.4

7.1

2.5

6.3

Vmax,Fp@Vbus

=310Vdc


m/s

7.1

3.2

3.4

2.7

1.4

3.3

0.9

3.1

Vmax,0@Vbus

=310Vdc


m/s

20.5

9.7

10.0

7.9

4.8

9.6

3.8

8.3

Vmax,Fc@Vbus

=537Vdc


m/s

26.6

12.4

12.9

10.5

6.1

12.7

4.9

11.3

Vmax,Fp@Vbus

=537Vdc


m/s

12.5

5.8

6.1

5.0

2.8

6.1

2.2

5.7

Vmax,0@Vbus

=537Vdc


m/s

35.7

16.9

17.4

13.9

8.3

16.7

6.7

14.4

Mover Mass

Mp

Kg

1.3

1.3

2.6

2.6

4.9

4.9

3.8

3.8

Stator Mass

 Within

 unit length

Ms

Kg/m

3.4

3.4

3.4

3.4

3.4

3.4

3.4

3.4





Mover Dimension



Mover Model

Mover Length

M

Mover  mounting
hole A

K

LSMF610701A-S-H-NC-N-C00.5

101

1

4

22.5

LSMF610702A-S-H-NC-N-C00.5

200

3

8

16

LSMF610702B-S-H-NC-N-C00.5

200

3

12

16

LSMF610703A-S-H-NC-N-C00.5

368

6

14

16

LSMF610703A-P-H-NC-N-C00.5

368

6

14

16

LSMF610704A-S-H-NC-N-C00.5

278

4

10

27

LSMF610704A-P-H-NC-N-C00.5

278

4

10

27

Notes:
1. Standard cable length is 0.5m (with aviation plug), Continuous current Ic≤10A/10＜Ic≤12A/ 12＜Ic≤16A maximum outer diameter of used cable is 7.5mm/8.0mm/9.0mm, the fixed laying minimum bending radius is 3*dmm, the moving minimum bending radius of chain is 5*dmm the cable length and terminal can be customized if there are special requirements;
2. Optional temperature sensor



Stator Dimension

Stator  Model

Stator Length
TL

N

Stator mounting hole B

LSMF6201E

168

3

8

LSMF6202E

252

5

12

LSMF6203E

420

9

20

Suitable for any mover of this series
