Robotic Laser Cleaning System

Machine Features

1. Laser cleaning is a process that applies high-energy laser beams to irradiate workpiece surfaces. Rust, paint, coatings, plating layers and contaminants on surfaces vaporize or peel off instantly to realize surface purification.

2. The working principle of laser cleaning machines: surface contaminants absorb laser energy, then vaporize or expand rapidly under instantaneous heating. They break free from surface adsorption force and separate from substrates to complete cleaning.

Applications

Application industries: high-speed railway, marine, automotive, mold, rail transit, machinery, sheet metal, electric power and more.

Technical Data Sheet

Laser Type

Fiber Laser / All-solid-state Laser

Laser Power

100/200/500/1000W

Laser Wavelength

1064nm

Cooling Method

Water-cooled

Water Temperature

20℃

Cleaning Width

10-100mm

Galvanometer Scanning Speed

＜4m/s

Outline Dimensions

5000mm×4000mm×2000mm (Robotic type)

Robot Repositioning Accuracy

±0.05mm

Robot Working Radius

Optional
