Picosecond laser marking system EP-IRPS-20
Page view:

Picosecond laser marking system EP-IRPS-20

Summary information
1. Good beam quality, small spot size for ultra-fine marking.
2. The heat affected zone is small, avoiding damage to the processed material and high yield.
3. Marking speed, high efficiency, high precision.
4. No consumables, low cost of use and maintenance.
5. The machine performance is stable, long-term operation.
Affiliate classification
没有此类产品
Product description

Application:

1. Cutting and drilling of brittle materials such as glass, sapphire and ceramics.

2. LCD, OLED screen cutting (C, R, U angle cutting)

3. Ultra-precise Mark points on the glass material, fine invisible QR code (0.2mm) and other fine marks

4. Metal medical equipment processing traceable mark with anti-etching, anti-oxidation and other functions

5. Cutting and drilling or surface coating removal on plastics, oxides and organics



Specification:

Machine model

EP-IRPS-20

Laser wavelength

1064nm

Laser power

20W / 10ps / 1000kHz

Repeated frequency

1000KHz

Marking scope

100*100mm

Marking line width

≤0.03mm

Marking depth

≤0.1mm

Min. character

0.06mm

Marking speed

≤7000mm/s

Repeated accuracy

±0.01mm

Power supply

AC 220V, 50Hz, 16A

Total power consumption

≤1.5kW
